| Installation |
Landscape |
| LCD Panel |
|
70-inch-class (69 1/2-inch [176.6 cm] diagonal) UV2A*1 LCD |
60-inch-class (60 1/16-inch [152.5 cm] diagonal) UV2A*1 LCD |
| Max. Resolution |
1,920 x 1,080 pixels |
| Max. Display Colours (approx.) |
1.06 billion colours |
| Pixel Pitch (H x V) |
0.802 x 0.802 mm |
0.692 x 0.692 mm |
| Max. Brightness (average)*2 |
300 cd/m2 |
| Contrast Ratio |
3,000 : 1 |
| Viewing Angle (H/V) |
160°/160° (CR ≧ 10) |
Active Screen Area
(W x H) (approx.) |
1,538.9 x 865.6 mm
(60 9/16" x 34 1/16") |
1,329.1 x 747.6 mm
(52 5/16" x 29 7/16") |
| Response Time |
6 ms (grey to grey, avg.) |
| Backlight |
LED, edge lit |
| Touchscreen |
Touch Technology |
IR (infrared blocking detection method) |
| PC Connection Port |
USB (2.0 compliant) (Type B) x 2 |
| Power Supply |
Supplied from main unit |
| Multi Touch |
10 points |
| Protection Glass |
Thickness: Approx. 3.4 mm*3
Shock resistance: 130 cm*4 |
Thickness: Approx. 3.0 mm*3
Shock resistance: 130 cm*4 |
| Touch Pen |
Communication |
Wireless communication method |
| Function Button |
Yes |
| Wireless Controller |
|
Wireless communication method (2.4 GHz, IEEE802.11 b/g/n) (5 GHz, IEEE802.11 a/n) |
| LAN Terminal |
10Base-T/100Base-TX |
| USB Port |
USB (2.0 compliant) (Type A) x 1 |
| Wireless Adapter Port |
USB (2.0 compliant) (Type A) x 1 |
| Computer Input |
Video |
Analogue RGB (0.7 Vp-p) [75Ω], DisplayPort™ 1.1a |
| Synchronisation |
Horizontal/vertical separation (TTL: positive/negative),
Sync on green*5, Composite sync (TTL: positive/negative)*5 |
| Plug & Play |
VESA DDC2B |
| Power Management |
VESA DPMS |
| Video Colour System |
NTSC (3.58 MHz, 4.43 MHz), PAL, PAL60, SECAM |
| Input Terminals*6 |
PC analogue: Mini D-sub 15-pin x 2*7,
HDMI™ (HDCP and 1080p compatible, PC/AV signal compatible) x 3, 3.5 mm-diameter mini stereo jack x 2,
Video x 1*7,
Component video x 1*7,
DisplayPort (HDCP compatible, PC signal compatible) x 1, RS-232C x 1*8 |
| Output Terminals*6 |
3.5 mm-diameter mini stereo jack x 1, DisplayPort (HDCP compatible) x 1 |
| Input/Output Terminals*6 |
LAN port (10Base-T/100Base-TX) x 1 |
| Speaker Output |
Built-in |
10 W + 10 W |
| External |
10 W + 10 W (6Ω) |
| Mounting |
VESA (4 points), 400 x 200 mm pitch, M6 screw |
| Power Supply |
100V – 240V AC, 50/60 Hz |
| Power Consumption |
235 W |
190 W |
Environmental
Conditions |
Operating Temperature |
5℃ to 35℃ |
| Operating Humidity |
20% to 80% RH (no condensation) |
Dimensions (W x D x H) (approx.)
(display only) |
1,647 x 94 x 1,010 mm
(64 13/16" x 3 11/16" x 39 3/4") |
1,437 x 94 x 890 mm
(56 9/16" x 3 11/16" x 35 1/16") |
| Weight (approx.) |
61 kg (134.5 lbs) |
48 kg (105.9 lbs) |
| Main Accessories |
AC power cord, remote control unit, battery (AA size x 2), set-up manual, blank sticker, cable clamps x 5, camera mount, USB cable (3.0 m), eraser, pen tray,touch pen (with function button), pen adapter, touch pen battery (AAA size), SHARP Display Connect software CD-ROM, wireless token, wireless adapter, wireless adapter cover, RS-232C conversion cable (3.5 mm-diameter mini stereo jack) x 1 |
